Window Mount Panel Antenna (N-Female) | 304452

Discontinued
email me this page
Email me this page

Works on every network, on any carrier.

Product Description

8 x 7 x 2 in. 4G Building cellular antenna, white panel, 50 Ohm, Directional, Window mount, 9 in. pigtail with N-Female connector.
Warning

Warning: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

Specs

Model Number:304452
Frequency700-800 MHz5.2 dB
824-894 MHz4.4 dB
880-960 MHz4.2 dB
1710-1880 MHz10.1 dB
1850-1990 MHz10.6 dB
2110-2170 MHz8.2 dB
Impedance50 Ohms
Maximum Power50 watts
PolarizationVertical
ConnectorsN-Female
Dimensions8.27 x 7.09 x 1.73 inches, 21 x 18 x 4.39 cm
VSWR1.5:1
Beamwidth Horizontal Plane70°/60°
Beamwidth Vertical Plane50°/45°
Ground PlaneBuilt-in Ground Plane
Price$ 89.99

Review Snapshot

Ratings Distribution


    Q&A

    Showing 10 out of 2 Questions

    Asked by Ellen a year ago

    Question: We live in a rural community. I can get a fair signal on my porch. Do you think this booster will help?

    Answer: Well, this is only the outside antenna but you may fair fine with a Home 4G but depending on your signal and size of home you may want a bigger amplifier. I suggest calling our customer support at 866-294-1660 or our online support at [email protected] to gain more information about your specific area. They should be able to recommend an amplifier from there. Thank you!

    Was this question helpful to you? Yes: 0 No: 0


    Asked by Kerry 4 years ago

    Question: Can you send me detailed specs on this antenna including the gain vs. frequency plot and antenna pattern plot as well. Interested in 700 MHz - 1.9 GHz (continuous). Also is this unit available with either SMA or BNC connectors>

    Answer: The following is the information on the frequency gains: 700-800 5.2 DB 824-894 4.4 DB 880-960 4.2 DB 1710-1850 10.1 DB 1850-1990 10.6 DB 2110-2170 8.2 DB Unfortunately I do not have a picture of the plot pattern but it is 70° horizontal beam width and 50° vertical beam width. Please contact us by phone, email, or chat for more in depth information and to discuss the pattern plot. We can be reached at [email protected] or 866-294-1660.

    Was this question helpful to you? Yes: 0 No: 1


    BEFORE USE, you MUST REGISTER THIS DEVICE with your wireless provider and have your provider’s consent. Most wireless providers consent to the use of signal boosters. Some providers may not consent to the use of this device on their network. If you are unsure, contact your provider. You MUST operate this device with approved antennas and cables as specified by the manufacturer. Antennas MUST be installed at least 20 cm (8 inches) from any person. You MUST cease operating this device immediately if requested by the FCC or a licensed wireless service provider.

    Warning.

    E911 location information may not be provided or may be inaccurate for calls served by using this device. Please note, the four largest carriers, namely, AT&T, T-Mobile, Verizon and Sprint, and more than 90 regional carriers have given a blanket consent to all boosters meeting the new certification standards
