4G Slim Low-Profile Antenna | 314401

email me this page
Email me this page

Works on every network, on any carrier.

Product Description

The weBoost 4G Slim Low-Profile Antenna compact design makes it simpler to install, while giving you improved performance over previous models.  When connected to any weBoost multi-user cellular booster, this antenna provides enhanced reception of calls, texts and data to the booster, providing superior performance when connected in your car, truck or SUV.  Installation is simple: place the antenna vertically or horizontally and you’ll still get optimal performance.  This antenna will work with any weBoost multi-user vehicle boosters, including the Drive 4G-X, Drive 4G-X Fleet, Drive 4G-X OTR, and Drive 4G-M

Warning

Warning: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

Specs

Model Number:314401
Frequency698-960 MHz2.3 dB
1710-2170 MHz2.5 dB
2500-2700 MHz5.1 dB
Impedance50 Ohm
PolarizationLinear
ConnectorsSMA Male
Mount TypeVelcro / Adhesive
DimensionsCoax Cable: LMR100 - 10 ft / 4.27 m, 3.2 x 1.4 x .5 / 83 x 35 x 13.3
Weight0.23 / 0.104
Radiation PatternOmni-Directional
Price$ 29.99

Resources

Review Snapshot

Ratings Distribution


    Q&A

    Showing 10 out of 4 Questions

    Asked by Josh 4 months ago

    Question: Will this work with the drive sleek so I dont have to use the cradle?

    Answer: Thank you for your question! This antenna will not work because the Sleek is designed for the cradle specifically. You might be able to connect it with a connector but you'll still have to have the phone on top of the antenna to receive coverage since it's a cradle amplifier. If there's any other questions or concerns, please let us know by calling our customer support at 866-294-1660 or our online support at [email protected] Thanks again!

    Was this question helpful to you? Yes: 0 No: 0


    Asked by Connor 4 months ago

    Question: How much is it per month

    Answer: Thank you for your question! Our amplifiers don't have a monthly cost since it's an all-in-one unit. It simply takes the signal that is available outside and amplifies it to make it more reliable inside your home, office, or vehicle. If there's any other questions or concerns, please let us know by calling our customer support at 866-294-1660 or our online support at [email protected] Thanks again!

    Was this question helpful to you? Yes: 0 No: 0


    Asked by OlorinTharkun 10 months ago

    Question: What is the range inside the vehicle of this antenna? If I place it next to my climate controls in the front of the vehicle, will the booster be effective for passengers in the 2nd row of seats (crew cab pickup)?

    Answer: Thank you for your question! It depends on the signal outside but most likely it's not going to cover much area. You'll only receive enough for the front 2 passengers but not the full vehicle. Please let us know if there's anything else we can assist with by calling our customer support at 866-294-1660 or our online support at [email protected] Thank you!

    Was this question helpful to you? Yes: 0 No: 0


    Asked by [email protected] a year ago

    Question: Is this the antenna that receives signal from the cell towers, or is this the antenna that sends the signal from the weBoost unit to the cell phones inside the car? I broke my outside antenna in a car wash and I need to replace it. Will this work?

    Answer: This is the inside antenna for a mobile unit. You'll need the 301126 for the outside antenna.

    Was this question helpful to you? Yes: 0 No: 0


    BEFORE USE, you MUST REGISTER THIS DEVICE with your wireless provider and have your provider’s consent. Most wireless providers consent to the use of signal boosters. Some providers may not consent to the use of this device on their network. If you are unsure, contact your provider. You MUST operate this device with approved antennas and cables as specified by the manufacturer. Antennas MUST be installed at least 20 cm (8 inches) from any person. You MUST cease operating this device immediately if requested by the FCC or a licensed wireless service provider.

    Warning.

    E911 location information may not be provided or may be inaccurate for calls served by using this device. Please note, the four largest carriers, namely, AT&T, T-Mobile, Verizon and Sprint, and more than 90 regional carriers have given a blanket consent to all boosters meeting the new certification standards
